TECHNICAL MANUAL BLUE PAPER GAIN · HYDRO 202136 | ORBEA ORBEA | 37
EN
11 TECHNICAL SPECIFICATIONS
GAIN HYDRO
MATERIAL
Frame ALUMINUM 6061
Fork
Fork blades: carbon
Steerer tube: carbon
Recommended use ALL ROAD EBIKE
Available sizes XS, S, M, L, XL
Ebikemotion® remote controller IWOC ONE
'DKMGOQVKQPKPVGTPCNDCVVGT[ƂZKPI 8'46+%#.+061&19067$'
'DKMGOQVKQP4CPIG'ZVGPFGTDCVVGT[ƂZKPI Seat tube
Stem
OC COMPONENTS
ICR headset internal cabling
Fork´s rake 50mm
/CZKOWOPWODGTQHJGCFUGVURCEGTU 30mm
Fork steerer tube TAPERED 1" 1/8-1" 1/2
(QTMNGPIJVCZNGVQETQYP) 400mm
Headset bearings
UPPER 1" 1/2 (WITH ADAPTER 1 1/2" - 1 1/8" FOR INTERNAL CABLING)
LOWER 1" 1/2
Wheel size 700C
6[TGOCZKOWOYKFVJ
700x40C
Tyre maximum external diameter: 702mm
Bottom bracket PRESSFIT (PF86)
BB shell width 86.5mm
Fork dropout standard 12x100mm
(TQPVCZNGOGCUWTGOGPVU 12x119mm
(TQPVCZNGVJTGCFRKVEJ &17$.'.'#&/#8+%52''&4'.'#5'2
(TQPVCZNGVJTGCFNGPIJV 13mm
Rear dropout standard Ebikemotion X35. 135x10mm
4GCTCZNGOGCUWTGOGPVU Ebikemotion X35 motor
4GCTCZNGPWVUVJTGCFRKVEJ
M12
1.25mm
Seatpost diameter 27.2mm
Seatpost clamp 31.8mm
Front derailleur
DOWN PULL.
$4#<'104'/18#$.'/'%**#0)'4
Front derailleur angle 63º - 66º
$KITKPIOCZUK\G 53T
5OCNNTKPIOCZUK\G 46T
1XCNTKPIOCZUK\G 50T
Triple chainset compatible NO
Chainline
Shimano 2X Road Groupsets: 43.5mm
Shimano AllRoad 2X Groupsets: 46.9mm
Shimano AllRoad 1X Groupsets: 49.7mm
Minimum Q-factor 146mm
/CZKOWOETCPMNGPIJV 175
Rear derailleur hanger Standard derailleurs. No direct mount
Drivetrain compatibility
5JKOCPQ841#&#..41#&
841#&#..41#&
Dura Ace not compatible
5TCO841#&
841#&0Q:&Q:&4
1PN[5JKOCPQ5URNKPGECUUGVVGU
:&/KETQURNKPGECUUGVVGUPQVEQORCVKDNG
Front brake DISC. FLAT MOUNT*
/KPOCZHTQPVTQVQTFKCOGVGT 160/160mm
Rear brake DISC. FLAT MOUNT*
/KPOCZTGCTTQVQTFKCOGVGT 160/160mm (with 20mm adaptor)
4GCTECNKRGTƃCVOQWPVƂZKPIDQNVNGPIJV
(Chainstay height = 25mm)
Shimano = 38mm
Sram = 32mm
Cabling
Internal (brakes, gears and x35) through headset, downtube and chainstays
Full sleeve
Internal front brake routing through fork blade
Bottle holder 2. ALL SIZES
Compatible DI2 and EPS NO
/WFIWCTFUVJTGCFUQPHTCOGHQTM NO
Rack compatible NO
Childseat compatible NO
Trailer compatible NO
Powermeter compatibility**
QUARK: YES
STAGES: YES
SRM: YES
Lights
Front light integrated in cycle computer mount
Rear light integrated in seatpost
UCI legal NO
* Not all calipers and rotors in the market are compatible with all frames.
#NNEQORQPGVUURGEKƂECVGFHTQO1TDGCJCXGDGGPVGUVGF(QTCHVGTOCTMGVQRVKQPUEJGEMEQORQPGPVGUFKOGPUKQPUCPFVQNGTCPEGU
befores purchasing.
** For other powermeters, consult the compatibility and dimensions with the manufacturer.

Orbea GAIN D40 Specifications

General

Fork	Carbon
Motor	Ebikemotion X35
Crankset	Shimano Tiagra 4700 34x50t
Chain	KMC X10
Weight	13.5 kg
Frame Material	Aluminum
Drivetrain	Shimano Tiagra
Tires	Vittoria Zaffiro 700x30c
Stem	OC1 31.8mm
Handlebar	Orbea OC-II
Rear Derailleur	Shimano Tiagra
Shifters	Shimano Tiagra
Wheels	Ready GR
Seatpost	Orbea OC-II
Saddle	Selle Royal
Display	Ebikemotion X35
Charger	Ebikemotion X35
