BLUE PAPER KERAM BOSCH GEN4 20206 | ORBEA ORBEA | 7 TECHNICAL MANUAL
TECHNICAL SPECIFICATIONS
FRAME MATERIAL
ALUMINUM
INTENDED USE MTB: CROSS COUNTRY, TRAIL
ASPHALT: URBAN, LEISURE
COMFORT: URBAN, LEISURE
SIZES S,M,L,XL
FORK TRAVEL MTB: 100MM O 120MM
ASPHALT: RIGID FORK
COMFORT: 63MM
WHEEL SIZE 700C-29"
MAX. TYRE SIZE 29"X2.4
FORK OFFSET 42MM OR 51MM. DEPENDING ON MODEL
BOTTOM BRACKET MOTOR BOSCH GEN4
HEADSET INTEGRATED 1 1/8-1 1/2
REAR AXLE STANDARD 135MM X 9MM QR
SEATPOST DIAMETER 31.6MM
SEATPOST CLAMP DIAMETER 34,9MM SPECIFIC KERAM 19 FRAME
FRONT DERAILLEUR N/A. 1X ONLY
CHAINRING MAXIMUM SIZE 38T
MAXIMUM CRANK LENGHT 170MM
BRAKES DISCO POST MOUNT *
REAR ROTOR MX. SIZE 180MM
REAR ROTOR MIN. SIZE 160MM
CHAINGUIDE
NO
ICGS NO
CABLING INTERNAL (FULL SLEEVE)
LEFT-ROAD CABLING READY
YES. ALL CABLES ENTER THE FRAME
ON THE LEFT SIDE
BOTTLE HOLDER 1. ALL SIZES
COMPATIBLE DI2 NO
COMPATIBLE SRAM AXS YES
DRIVETRAIN COMPATIBILITY 10, 11 AND 12 SPEED
COMPATIBILIDAD POTENCIÓMETRO NO
INTERNAL BATTERY YES. IN DOWNTUBE. 400WH OR 500WH. BOSCH POWERPACK
DUAL BATTERY OPTION
YES. ONLY AS A COMPLETE OPTION AT THE MOMENT
OF PURCHASE. NOT COMPATIBLE WITH SIZE S FRAME
MOTOR
ONLY BOSCH GEN4 AND GEN3
(USES DIFFERENT MOTOR MOUNTING PLATES)
DISPLAY BOSCH PURION
MOTOR ASSEMBLY ANGLE 6,5º
* Not all calipers and rotors in the market are compatible with all frames.
All componets specicated from Orbea have been tested. For aftermarket options, check componentes
dimensions and tolerances before purchasing.
NOTE: This technical document describes the Keram
models (MTB, Asphalt and Comfort) equipped with
a Bosch Gen4 motor. For 2019 and onwards models
equipped with a previous generation Bosch motor,
consult the technical document Bluepaper Keram 2019
from the manuals section of the Orbea´s website.
