TECHNICAL MANUAL BLUE PAPER LAUFEY 202010 | ORBEA ORBEA | 11
SEATCLAMP MTB 34.9 LAUFEY 20
03 ART Nº: 11160004 QUANTITY
SEATCLAMP MTB 34.9 LAUFEY 20 1
RUBBER CHAINSTAY PROTECTOR LAUFEY 20
04 ART Nº: 11000526 QUANTITY
RUBBER CHAINSTAY PROTECTOR LAUFEY 20 1
CABLEGUIDES+GROMMET KIT LAUFEY 20
05 KIT Nº: Y0000145 QUANTITY
5.1
RUBBER GROMMET 22,8 4
5.2
BOLT 5x10 2
5.3
CABLE GUIDE GEAR+BRAKE 2
WASHER INOX M5 2
FRAME HARDWARE
4
5 Nm
5.1
5.1
5.3
5.2
3
4
3
5 Nm
Serie 200
