Orbea RALLON - Parts and Hardware; Rear Axle Component Assemblies

TECHNICAL SPECIFICATIONS
5
PARTS & HARDWARE
1
9 9
2 3 34 45 106 7 118 4 43 12
Number Name/Description
1
12 MM THRU AXLE
2
12 MM AXLE WASHER
3
OCP NUT
4
BEARING 26X17X5
5
LEFT DROPOUT
6
LEFT DROPOUT INSERT
7
RIGHT DROPOUT INSERT
8
HANGER
Number Name/Description
3
OCP NUT
4
BEARING 26X17X5
9
9 MM THRU AXLE
10
LEFT DROPOUT 9 MM
11
RIGHT DROPOUT 9 MM
12
OCP RIGHT NUT 9 MM
