TECHNICAL SPECIFICATIONS
6
17
4
16
18
19
20
20
19
21
15
14
13
Number Name/Description
4
BEARING 26X17X5
13
MAIN PIVOT AXLE
14
MAIN PIVOT O-RING
15
MAIN PIVOT SPACER
16
M6X20
17
BEARING 24X15X5
18
MAIN PIVOT WASHER
Number Name/Description
19
SEATSTAY/LINK SPACER
20
BEARING 19X10X5
21
SEATSTAY/LINK BOLT

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Orbea RALLON and is the answer not in the manual?

Orbea RALLON Specifications

General IconGeneral
Wheel Size29"
SuspensionFull Suspension
Frame MaterialCarbon
CategoryEnduro
Intended UseEnduro
BrakesShimano or SRAM (various models)
