TECHNICAL SPECIFICATIONS
7
1724
23
17 2419 20 22
25
Number Name/Description
19
SEATSTAY/LINK SPACER
20
BEARING 19X10X5
22
LINK/FRONT TRIANGLE BOLT
Number Name/Description
17
BEARING 24X15X5
24
STANDARD SHOCK SPACER
24
BOS KIRK SHOCK SPACER
25
LINK/SHOCK BOLT

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Orbea RALLON and is the answer not in the manual?

Orbea RALLON Specifications

General IconGeneral
Wheel Size29"
SuspensionFull Suspension
Frame MaterialCarbon
CategoryEnduro
Intended UseEnduro
BrakesShimano or SRAM (various models)
