TECHNICAL SPECIFICATIONS
8
282726
36
40 29
30
31
30
37
30
3435
3832
33 39
29
29
Number Name/Description
26
SHOCK/FRONT TRIANGLE NUT
27
SHOCK/FRONT TRIANGLE WASHER
28
SHOCK/FRONT TRIANGLE BOLT
Number Name/Description
29
M5X15
30
DOWNTUBE CABLE GUIDE
31
DOWNTUBE PROTECTOR
32
CHAINSTAY PROTECTOR
33
SEATSTAY PROTECTOR
34
ISCG05 ADAPTER
35
ISCG ADAPTER BOLT (M6X15)
36
SEAT POST CLAMP
37 (S)
FRONT TRIANGLE (16,5”)
37 (M)
FRONT TRIANGLE (18”)
37 (L)
FRONT TRIANGLE (19,5”)
38
CHAINSTAY
39
SEATSTAYS
40
LINK
