Orca 40 CL - Page 107

107
ENTRETIEN
Wielhoek
Looppad
Wielhoek
Looppad
Instelling 2: B-C, wanneer de draaihoek te groot is
Instelling 3: C-C, wanneer de lengte an breedte van he zwembad groot zijn
BEDIENINGSINSTRUCTIES
10
Setting 3: C-C, when the length and width of the swimming pool are large
Wheel Angle
Running route
10
Setting 3: C-C, when the length and width of the swimming pool are large
Wheel Angle
Running route
8
Then re-install the limit pile into chassis to realize the different running paths.
b. Four settings for wheels are recommended:
Setting 1: default setting: B-C, for most of pools
Wheel Angle
Running path
9
Setting 2: C-A, when the turning angle is too large
Wheel
Angle
Running
path
