27
Wheel Angle
Running path
Wheel Angle
Running path
Setting 2: B-C, when the turning angle is too large
Setting 3: C-C, when the length and width of the swimming pool are large
OPERATING INSTRUCTION
8
Then re-install the limit pile into chassis to realize the different running paths.
b. Four settings for wheels are recommended:
Setting 1: default setting: B-C, for most of pools
9
Setting 2: C-A, when the turning angle is too large
10
Setting 3: C-C, when the length and width of the swimming pool are large
10
Setting 3: C-C, when the length and width of the swimming pool are large
