11
ROTARY COVER (1, FIGURE 6)
The blade spins at a high speed inside the cover. This cover
prevents cut grass and foreign objects from scattering.
FRONT COVER (2, FIGURE 6)
This opens and closes automatically depending on the quantity of
grass. This prevents cut grass and foreign objects from scattering
forward.
SAFETY COVER (3, FIGURE 6)
This prevents cut grass and foreign objects scattering from
coming at the mower.
WARNING
The covers are the really important parts to protect from thrown objects.
Do NOT attempt to operate the machine if the covers are in abnormal conditions. Make sure to
follow the instruction below.
1. If Rotary cover, Front cover or Safety cover is damaged or deformed, have it repaired or
replaced.
2. Do NOT attempt to operate the machine without Front cover and Safety cover.
3. Do NOT attempt to operate the machine with Front cover fixed. Fix Front cover ONLY when
replacing the blade or cleaning inside of the cover.
