OREC RM83G - © SAT 03/2015
Brake
If the brake is not worked efficiently, tighten it with the nut
(B, Figure 28 / RM83G, C Figure 12b / RM830).
Tightening bolts
Check that the bolts, nuts…are properly tightened. The
vibrations tend to loosen the bolts.
Adjust safety switches
Ajust the screws for pushing the safety switches so they can
push switches from 3 to 5 mm.
Speed lever adjustment
Ajust the control link (A, Figure 29) in order to have the
machine staying still when the lever is at neutral.
DIFF LOCK LEVER ADJUSTMENT
Ajust the control wire (B, Figure 29) until the lever has
a free play of 1 to 3 mm before activate the diff lock.
