BREAKDOWNS AND SOLUTIONS
PROBLEME
CAUSE
SOLUTIONS
No fuel
Refuel the tank
Battery is empty
Load or replace the battery
Engine does not start
Safety switches are working
Check brakes, blade clutch and seat
and Speed lever
The machine does not travel
Parking brake is locked
Unlock parking brake
The machine does not stop
Speed lever is not on « N »
Move the Speed lever to « N »
The blade does not rotate
Blade clutch lever is not
engage
Engage Blade clutch lever
Safety switches are working
Check brakes, blade clutch and seat
and Speed lever
TIGHTENING TORQUES (Nm)
DIAMETER OF THE
SCREW (mm)
MARKS ON THE SCREW HEAD
4 7 8 9 11
3
0,3 to 0,5
---
---
---
---
4
0,8 to 1,0
---
---
---
---
5
2,5 to 3,4
5,4 to 6,4
6,4 to 7,4
6,4 to 7,4
8,8 to 9,8
6
4,9 to 6,9
9,8 to 11,8
11,8 to 13,7
11,8 to 13,7
14,7 to 16,7
8
11,8 to 16,7
24,5 to 29,4
29,4 to 34,3
34,3 to 36,2
36,3 to 41,2
10
20,6 to 29,4
39,2 to 44,1
49 to 53,9
49 to 53,9
72,6 to 82,4
12
44,1 to 53,9
83,4 to 93,2
93,2 to 107,9
93,2 to 107,9
122,6 to 137,3
14
63,7 to 78,5
117,7 to 132,4
132,4 to 147,1
147,1 to 166,7
205,9 to 225,6
16
88,3 to 107,9
152 to 171,6
176,5 to 196,1
215,8 to 245,2
313,8 to 343,2
18
117,7 to 137,3
205,9 to 235,4
245,2 to 274,6
313,8 to 343,2
441,3 to 470,7
20
147,1 to 166,71
235,4 to 274,6
313,8 to 353
441,3 to 480,5
617,8 to 657,1
22
176,5 to 205,9
421,7 to 451,1
539,4 to 578,6
608 to 647,2
843,4 to 882,6
24
235,4 to 264,8
539,4 to 568,8
706,1 to 745,3
784,5 to 823,8
1098,4 to 1137,6
Or without mark
