Oreck Graphite - Assembling The Handle Tube; Operating The Vacuum; Replacing The Hepa Filtration Odour Fighting Bag

4
ENGLISH
Assembling the Handle Tube
Up-Position Lock - Placefootonpowerheadandleanhandlebackgentlytoreleaselockforvacuumuse.
Return handle to the full upright position to engage lock. Note: Do not operate the unit while in the upright and
lockedposition.Donotlettheunitrunwhileinanyonestationarypositionforanyperiodoftime. 
Keeptheunitmovingwhileinoperation.
Easy Power Cord Storage - Wrap power cord around cord hook on handle and cord hook on connector.
Beforeassemblingappliance,removetwoscrewsfromtheConnectorAssembly.Removecardboardinsertby
pulling upward.
SlideupperhandlesectionoverthematchingsectionoftheConnectorAssembly.HoldtabofCordStrainRelief
flushwithTOPholeinConnectorAssembly.InsertscrewthroughholeintabofCordStrainReliefandfirmly
tightentoConnectorAssembly.InsertremainingscrewinbottomholeofConnectorAssemblyandtightenfirmly.
LoopthePowerCordthroughthe
StrainReliefKitasillustrated
Take hold of the Harness (21 on
parts list pg 3) - and push it into the
clip located on the left side of the
ConectorDeflectorAssembly(10
on parts list).
Operating the Vacuum
MakesuretheHEPAFiltrationOdourFightingBagisinplace.DONOToperatethecleanerwithoutadustbag.
PlugthepowercordintoanelectricaloutletandpresstheOn(l ) - OFF ( O )switchonhandleassemblywhen
ready to operate.
1
2
3
4
5
Operation
4
5
5
WARNING:Unplugcordfromelectricaloutletbeforeservicing.
BAG REMOVAL:
Unzipouterbagcompletely.
Pullbagcardboardcollartoreleasebagdockdoorfromconnector.Bagdockdoorwillhingedownward.
Gently pull bag cardboard collar upward out of the bag dock. Saniseal
®
dustsealwillcloseautomatically.
BAG INSTALLATION:
Slidethecardboardcollarcompletelyontobagdockdoor.
Firmlypushbagdockdoorwithboththumbsonindicationpointuntilitsnaps.
Replacing the HEPA Filtration Odour Fighting Bag
6
7
8
9
10
6 7 8 9 10
Connector
Assembly
TAB
3
1
2.1
2
2.1
