Oreck Graphite User Manual

ENGLISH
IMPORTANT:Onplushandnewcarpets,stuffingmayoccurinsidetheintaketubeandthelowertube
assembly.Thisisduetoexcessivefuzzandloosecuttingsinthecarpet.Stuffingcouldoccurforthefirstfew
cleaningsuntilalltheloosematerialisremoved.Duetothehighefficiencyofthecleaner,manyoldercarpets
willcausestuffingwhenthecleanerisfirstusedonthem.Ifyourvacuumcleanerdoesnotpickupproperly,
ormakesunusualnoiseandtheouterbagdoesnotfluffuporballoonopen,followthesesteps:
WARNING:Unplugcordfromelectricaloutletbeforeservicing.
Checkforblockageatthemouthoftheintakeopening.Ifthereisblockage,removeitwithlong-nosepliers,
ascrewdriverorcoathanger.Ifyoucannotreachtheblockage,removebaseplate.Removethebaseplateby
removing5screws(see“AdjustingorReplacingBrushroll”).
Iftheblockageisnotatthebase,removelowertube.Unhookbagspring,releasingbottomofbag.
Twistlowercollaranticlockwisetoslideup.Pulltubeoutofbase.
Checkforblockage.Ifblockageisinthetube,removewithacoathanger.
Iftubeisnotblocked,lookintofanhousing.Removedebriswithlong-nosepliers,ascrewdriverorcoathanger.
Toreassemble,checkO-ringontube,andreplaceifdamaged.Replacetubebyfirstliningupslotatbaseof
tube with tab inside fan housing. Insert tube and push down until the tube is seated. Make sure O-ring is in
place against fan housing opening. Replace and tighten collar until collar locking tabs are locked in place.
Reattach bag spring.
Manytimesblockageoccursduetoafulldustbagcausingdirttobackdowntheairflowsystem.Whenthat
happens,theblockagewillbeatthetopofthesystem,startingintheareawherethedustbagconnectstothe
connectorassembly.
Note:Iftheaboveactionsdonotcorrecttheproblem,contactanOreckApprovedServiceCentreorcallthe
CustomerCareon08456030153
Stuffing or Blockage
Maintenance
23
24
25
26
27
25
28
23
24 25 26 27 28
8
Trouble-
shooting
Serviceproblemsthat
appeartobemajorcan
oftenbesolvedeasily.
Youcanbeyourown
troubleshooter by
reviewingthisguide.
Allotherservicing
should be done by an
OreckApproved
ServiceCentre.
Problem Check What to do
Cleanerwillnotrun. •Notpluggedinproperly. •Besurecleanerisfirmlypluggedintowalloutlet.
  •Noelectricityinwalloutlet. •Checkelectricalsource–fuseorcircuitbreaker.
 Cleanerdoesnotpickup. •Bagisfull. •Replacefilterbag.See“ReplacingtheHEPA
     FiltrationOdourFightingBag”.
  •Nozzleorintakepivot •Clearobstruction.
clogged.
  •Beltisbrokenorstretched. •Replacebelt.
  •Brushisworn. •See“AdjustingorReplacingBrushroll”.
  •Bagtubeclogged. •Clearobstruction.
  •Bagporesareclogged •Changebag.
with fine dust.
  •Impellerfanisbroken. •ReturntoOreckApprovedServiceCentreforrepair.
 Unitstilldoesnot •Checkallthe •ContactOreckCustomerCareforservice.
 operateproperly.  abovepoints.
