WARNING:Unplugcordfromelectricaloutletbeforeservicing.

Removethereplacementbeltfromthestoragechannel.

Removethedoorbyremovingthephillipsheadscrewlocatedonsideofpowerhead.

Folddoorawayfromthepowerheadandliftitaway.

Removethebeltfromthemotordriveshaftandbrushrollpulley.

Loopthenewbeltoverthebrushrollpulley.Placetheoppositeendofthebeltonthemotordriveshaft.

Replacethedoorbyplacingthebottomtabondoorintoslotslocatedinsidepowerheadandpressingthe

door closed.

Replace the phillips head screw and tighten.

Replacing Worn Belt

14 15

Maintenance

General

Information

Lubrication

Thevacuumcleanermotorbearingsarefactorylubricatedandsealed.Furtherlubricationisnotrequired.

CAUTION

Wood Floors, Soft (Vinyl, Asphalt Tile, etc.) Floor Surfaces and Polished Floor Finishes

Usefloorandfloorfinishmanufacturer’srecommendedmethodsofcleaning.The

rollerbrushmayalsoscuffverysoftfinishes.Donotoperatetheunitwhileinthe

upright and locked position. Do not let the unit run while in any one stationary posi-

tionforanyperiodoftime.Keeptheunitmovingwhileinoperation.

Note:Atleastonceamonth,checkforandremoveexcessivelint,stringorhairfrom

revolvingbrush.

Wipetheoutsideofthecleanerwithadampcloth.Alsocleantheconnectordeflector

assemblyarea,baseofcleanerandfanhousingarea.Ifthereisdustintheouterbag,

vacuumitorshakeitout.

Alittlepreventativemaintenancewillkeepyourcleanerlookingnewandwillensure

continuedcleaningeffectiveness.
