Oreck XL3910H2B User Manual

Part Numbers Listing: U3760HH / U3720HG / U3720HR
Hypo Bag, Lights, Helping Hand Handle, Antimicrobial Units
# Item Order # Qty. Pk.
4 Bag Dock Type CC Antimicrobial 75582-02-0327 1 1
5 Dust Bag, (8 Pk.) Hypo Allergenic CCPK8DW 1 8
Dust Bag, (25 Pk.) Hypo Allergenic CCPK25DW 1 25
6 Outer Bag, Blue Antimicrobial 75645-19 1 1
U3720HG: Outer Bag, Gray Antimicrobial 75645-26 1 1
U3720HR: Outer Bag, Red Antimicrobial 75645-27 1 1
7 Bag Clip Curved Antimicrobial 09-75776-01 1 1
U3720HG: Bag clip curved gray 09-75594-11 1 1
U3720HR: Bag clip curved red 09-75594-06 1 1
8 Connector Assembly Kit, includes items #3 & #84 09-75308-57 1 1
9 Collar Modified 75199-02-0327 2 1
10 Tube Assembly 75198-05 1 1
12 Fan Housing Assembly 09-75221-12 1 1
16 Endcard, Metal Pulley Brush, Rt 75704-01 1 1
18 METAXALLOY™ Fan Kit w/Washers 09-75300-01 1 1
19 Fan Cup Seal 75012-01 1 1
20 Cord Set see #59
21 U3720HG: Lamp Housing Gray Antimicrobial 75521-02-0384 1 1
U3720HR: Lamp Housing Red Antimicrobial 75521-02-444 1 1
21a Low Profile Lamp Housing Blue Antimicrobial 75763-01-466 11
22 U3720HG / U3720HG: Lense clear blue 75520-02-455 1 1
22a Lens, Low Profile Light Antimicrobial 75762-01-0329 1 1
23 Bulb Headlight 77051-01 2 1
U3720HG / U3720HG: Bulb Headlight 00965-0019 2 1
24 Label, XL Dome Blue on Silver 75772-02 1 1
U3720HG / U3720HG: Label Badge Black on Silver 73020-04 1 1
25 Lamp Holder 75539-01 1 1
26 U3760HH:
Top Cover, Blue, Antimicrobial 09-75780-30 1 1
U3720HG: Top Cover, Gray, Antimicrobial 09-75780-38 1 1
U3720HR: Top Cover, Red, Antimicrobial 09-75780-31 1 1
27 Bumper, Clear Antimoicrobial 75765-01 1 1
U3720HG / U3720HG: Bumper Clear with Blue Tint 75181-04 1 1
28 Intake Pivot Assembly, with Felt Seal 09-75066-02 1 1
29 Felt Seal 75065-01 1 1
32 Felt Seal, Motor 75117-01M 1 100
33
Cord Retainer
, Square 03-00655-01 1 1
34 Motor Assembly Kit 09-75505-01 1 1
35 Motor Seal 75095-01 2 1
36
Kit, Motor Brush / Spring
09-75514-01
22
39
Drive Belt, (3 Pk.)
0300604
13
39a Drive Belt, Single 75024-01 1 1
40 U3760HH: Belt Door Blue, Antimicrobial 75057-03-466 1 1
U3720HG: Belt Door
, Gray
,
Antimicrobial
75057-03-0384
1
1
U3720HR: Belt Door
, Red,
Antimicrobial
75057-02-444
1
1
1
1
