Page #3 background image
STANDARD FASTENER HARDWARE LISTING
Fasteners Fit Uprights Listed in Service Manual
# FASTENER FASTENER PART THAT FASTENER QTY TORQUE QTY
DESCRIPTION PART NO. IS USED ON REQ’D RANGE PER
(in/lb) PKG.
3
STANDARD PARTS
Kit Number Description
09-75505-01 Kit, Motor
75086-01 Leads, Red
75086-02 Leads, White NLA NLA NLA
75506-01
Leads, Green
03-00474-01M 100pc. Edge Brush Axle Kit, Pin, .125 x .5
75338-01 20pc. Edge Brush Wheel Kit
2 Cord Clamp 03-00619-01M 1 n/a 100
3 Screw, #8 - 32 x .440 Nylock 03-00478-02M Handle Tube 2 18 - 22 100
Screw, #8 x .811 w/ Int Washer 03-00608-01M Handle Tube w/Through Bolt 1 18 - 22 100
Screw, #8-32 X .545 w/ Washer 03-00504-02M Handle Brace 2 18 - 22 100
Screw, #8 - 32 x 29/32 w/ Washer 03-00605-01M Handle Brace w/Through Bolt 1 18 - 22 100
15 Screw, #8 - 10 x 1.25 Plt 30 03751M Headlight Cover
15 Screw, #8 X .5 Phillips 03752-01M Bulb Holder, Foot Switch, 2/2 13 - 16 100
Cable Clamp 1
30 1/4 X 32 Yellow Chrome 03-00448-01M Fan 1 18 - 20 100
38 Screw, #8 X .75 Phillips 03-00456-01M
D-Handle (small head) 4 17 - 20 100
Screw, #8 x .75 03-00476-01M D-Handle Type 6 Only 6 17 - 20 100
41 Wire Nut 03-00599-01M as req’d 35 - 55 100
48 Screw, #8 x .75 Phillips 03-00476-01M Baseplate, Belt Door, Intake Pivot, 5 / 1 / 1 13 - 16 100
Motor 2 17 - 20 100
49 Screw, #7 X .38 Phillips 03-00475-01M Edge Brush Type 4-6 Only, Detent 2 / 2 5 - 8 100
Silver Series Fascia & Bulb Holder 2 / 2 5 - 8 100
63 Screw, #10 x .5 Phillips 03-00450-01M Cord Bracket 1 13 - 16 100
69 O-Ring 75191-02M Collar 2 n/a 100
72 Washer, Thrust 03-00479-01M Fan 1 n/a 100
73 Washer, Lock External Tooth 03-00480-01M Fan 1 n/a 100
74 1” x 3”, Loop Fastener 75304-01M Bag Support 1 n/a 100
75 1” x 1”, Hook Fastener 75303-01M Bag Dock 2 n/a 100
77 Retainer Clip 03528M Baseplate Type 4-6 Serviceable 2 n/a 100
78 Wireform 75194-03M Baseplate Type 4-6 Serviceable 2 n/a 100
80 Steel Bushing Ring 03-00598-01M D-Handle 1 n/a 100
84 Nut, Square 03-00606-01M Connector 1 n/a 100
85
Screw
, #6-20 x 7/16 Flat Undercut
03-00626-01M
Corner Brush, Channel
T
ype 7 Only
2 / 3
6 - 8
100
86 Wireform, One-Piece 75698-01 Baseplate Type 7 Only 1 n/a 1
88 JST Insulator 75679-01M Harness 1 n/a 100
89
Rivet
03-00453-01M
Fan Housing
1 n/a 100
90 Bag Spring 75015-01M Fan Housing 1 n/a 100
91
Push Nut
03-00636-01M
Fan Housing 1 n/a 100
