31
PARTS INDEX
REF QTY 600RT
PART
720RT
PART
DESCRIPTION
1 1 1042319 1042319 Side drive assembly (see page 34)
2 1 1042304 1042304 Gearbox assembly, 1.46:1 1.50
hex (see page 35)
3 1031934 (14) 1031934 (18) Speed blade, RH
4 1031935 (14) 1031935 (18) Speed blade, LH
5 1 104391160 104391172 Hex shaft - 1.50
6 1 1043901 1043901 Mast plate, right
7 1 1043902 1043902 Mast plate, left
8 1 1043903 1043903 Skid shoe, left
9 2 1043904 1043904 Link, bolt on
10 1 1043905 1043905 Skid shoe, right
11 1 104390660 104390672 Tailgate
12 1 1043919 1043919 Link, tailgate mount
13 1 104390860 104390872 Shield, hex shaft
14 1 1043910 1043910 Parking stand
15 1 1034983 1034983 Snap ring, external, 40 mm
16 1031925 (28) 1031925 (36) 1/2 NC x 1-1/4 HHCS, GR8 w/
shank
17 2 33661RP 33661RP Category 1 mounting pin, w/ nut
& lock washer
17A 2 30007RP * 30007RP * Nut, hex 7/8 NF
17B 2 30008RP * 30008RP * Washer, lock 7/8
18 1 1002048 1002048 Clutch shield
19 1 1042365 1042365 Drive assembly, complete
(see page 33)
20 1 104391560 104391572 Rotor shaft
21 1 1043917 1043917 End plate
22 1 1043920 1043920 Gearbox mount
23 1 1043918 1043918 Bearing cover
24 1 3231* 3231 * 3/8 NC x 2 HHCS, GR5
25 2 14350* 14350 * 3/8 NC flange lock nut
26 2 W73163* W73163 * 5/16 NC flange whiz nut
REF QTY 600RT
PART
720RT
PART
DESCRIPTION
27 1 839* 839 * 3/8 NC x 1 HHCS, GR5
28 1 H019 H019 Lock pin, 3/8 x 2-1/4
33 2 1043088 1043088 Gasket
35 1 1042303 1042303 Seal, 40 x 70 x 10
36 1 1042352 1042352 Bearing asy, 6208 w/ seal
37 1031226 (28) 1031226 (36) 1/2 NC flange spiralock
38 4 39254* 39254* M8-1.25P x 14 mm HHCS, CL8.8
39 4 35155* 35155 * 5/16 SAE flat washer
40 4 2472* 2472 * 5/16 lock washer
41 1 44638 44638 Chain, 1/4 proof coil, 16 link
43 1 1026530 1026530 Manual storage tube
44 1 1972* 1972 * 1/4-28 tapered thread grease
fitting
45 10 3379* 3379 * 1/2 NC x 1-1/2 HHCS, GR5
46 6 6100* 6100 * 1/2 NC x 1-1/4 HHCS, GR5
47 10 25475* 25475 * 1/2 NC x 1 HHCS, GR5, full thread
48 22 11900* 11900 * 1/2 NC flange lock nut
49 2 16148* 16148 * 5/16 NC x 3/4 carriage bolt, GR5
50 4 57816 57816 1/2 SAE flat washer, hardened
51 2 24576* 24576 * 1/2 NC x 1-3/4 HHCS, GR5
53 1 1034984 1034984 Snap ring, internal, 80 mm
54 1 20891 20891 Ball bearing, 6208
55 1 15007* 15007 * 3/4 NC x 3-1/2 HHCS, GR5
56 1 1002018 1002018 Sleeve, .81 x 1.25 x 2.12
57 1 2371* 2371 * 3/4 NC hex lock nut
58 1 1031976 1031976 RT Tiller safety decal set (not
shown)
1 627819 627820 Decal, Model 600RT, OREGON /
Decal, Model 720RT, OREGON
HHCS: Hex Head Cap Screw
* Standard Hardware, Obtain Locally
