Operation Controls
and Functions
LCD Display Navigation
The buttons on the the front panel are used for LCD display navigation, includ-
ing INPUT(1~4), OUTPUT(1~4), MENU, ENTER, UP, DOWN.
Menu contents are as follows:
Level 1 Level 2 Level 3 Level 4
OUTPUT
SCALER OUT1/OUT2/OUT3/OUT4
BYPASS
8K to 4K
8K/4K to 1080P
AUTO
HDR OUT1/OUT2/OUT3/OUT4
BYPASS
HDR to SDR
AUTO
ARC OUT1/OUT2/OUT3/OUT4
ON
OFF
STREAM OUT1/OUT2/OUT3/OUT4
ENABLE
DISABLE
INPUT EDID IN1/IN2/IN3/IN4
z=1. 1080P, 2.0CH, z=2. 1080P, 5.1CH,
z=3. 1080P, 7.1CH, z=4. 4K30, 2.0CH,
z=5. 4K30, 5.1CH, z=6. 4K30, 7.1CH,
z=7. 4K60(420), 2.0CH, z=8. 4K60(420), 5.1CH,
z=9. 4K60(420), 7.1CH, z=10. 4K60(444), 2.0CH,
z=11. 4K60(444), 5.1CH, z=12. 4K60(444), 7.1CH,
z=13. 1080P_HDR, 2.0CH,
z=14. 1080P_HDR, 5.1CH,
z=15. 1080P_HDR, 7.1CH,
z=16. 4K30_HDR, 2.0CH,
z=17. 4K30_HDR, 5.1CH,
z=18. 4K30_HDR, 7.1CH,
z=19. 4K60(420)_HDR, 2.0CH,
z=20. 4K60(420)_HDR, 5.1CH,
z=21. 4K60(420)_HDR, 7.1CH
z=22. 4K60(444)_HDR, 2.0CH,
z=23. 4K60(444)_HDR, 5.1CH,
z=24. 4K60(444)_HDR, 7.1CH,
z=25. 4K120(420)_HDR, 2.0CH,
z=26. 4K120(420)_HDR, 5.1CH,
z=27. 4K120(420)_HDR, 7.1CH
z=28. 4K120(444)_HDR, 2.0CH,
(to be continued)
