Web GUI User Guide
The Matrix can be controlled by Web GUI. The operation method is shown as
below:
Step 1: Get the current IP Address.
The default IP address is 192.168.0.100. You can get the current Matrix IP ad-
dress in two ways:
The first way: You can get the IP address via panel buttons. On the initial LCD
display, press “MENU” button to enter the first level menu. Then press “UP/
DOWN” button to select “SETUP”, and press “ENTER” to enter the second level
menu. Then press “UP/DOWN” button to select “IP INFO”, and press “ENTER”
to check current IP address.
The second way: You can get the IP address via RS-232 control. Send the
ASCII command “r ipconfig!” through an ASCII Command tool, then you’ll get
the feedback information as shown below:
IP:192.168.0.100 in the above figure is the current Matrix IP address (this IP
address is variable, depending on what the specific machine returns).
For the details of ASCII control, please refer to “RS-232 Control Command”.
IP Mode: Static
IP: 192.168.0.100
Subnet Mask: 255.255.255.0
Gateway: 192.168.0.1
TCP/IP port=8000
Telnet port=23
Mac address: 00:1C:91:03:80:01
Step 2: Connect the TCP/IP port of the Matrix to a PC with a UTP ethernet
cable, and set the IP address of the PC to be in the same network segment
with the Matrix.
Step 3: Input the IP address of the Matrix into your browser on the PC to
enter Web GUI page. After entering the Web GUI page, there will be a Login
page, as shown below:
