RS-232
Control Command
Command Code Function Description Example Feedback Default
System Setting
s save preset z!
Save switch state between
all output port and the
input port to preset z, z=1~4
s save
preset 1!
save to preset 1
s recall preset z!
Call saved preset z
scenarios, z=1~4
s recall
preset 1!
recall from
preset 1
s clear preset z!
Clear stored preset z
scenarios, z=1~4
s clear
preset 1!
clear preset 1
r preset z!
Get preset z information,
z=1~4
r preset 1!
video/audio
crosspoint
Output Setting
s output y in
source x!
Route input x source to
output y (y=0~4, 0=all, x=1~4)
x=1. input 1, x=2. input 2
x=3. input 3, x=4. input 4
s output 1
in source
1!
output1->input1
output1->input1
output2->input2
output3->input3
output4->input4
r output y in
source!
Get output y selected input
source (y=0~4, 0=all)
r output 1
in source!
output1->input1
s output y hdcp
x!
Set output hdcp (y=0~4,
x=1~5)
x=1. HDCP 1.4
x=2. HDCP 2.2
x=3. Follow sink
x=4. Follow source
x=5. USER MODE
s output 1
hdcp 2!
output 1 HDCP:
HDCP 2.2
Follow sink
r output y hdcp!
Get output y hdcp status.
(y=0~4, 0=all)
r output 1
hdcp!
output 1 HDCP:
HDCP 2.2
s output y
stream x!
Set output y stream enable/
disable (y=0~4, 0=all, x=0~1)
x=0. stream disable
x=1. stream enable
s output 1
stream 1!
output 1 stream:
Enable
Enable
r output y
stream!
Get output y stream status.
(y=0~4, 0=all)
r output 1
stream!
output 1 stream:
Enable
