RS-232
Control Command
Command Code Function Description Example Feedback Default
EDID Setting
s input x EDID z!
Set HDMI input x EDID mode
(x=0~4, z=1~39)
z=1. 1080P,2.0CH,
z=2. 1080P,5.1CH,
z=3. 1080P,7.1CH
z=4. 4K30,2.0CH,
z=5. 4K30,5.1CH,
z=6. 4K30,7.1CH
z=7. 4K60(420),2.0CH,
z=8. 4K60(420),5.1CH,
z=9. 4K60(420),7.1CH
z=10. 4K60(444),2.0CH,
z=11. 4K60(444),5.1CH,
z=12. 4K60(444),7.1CH
z=13. 1080P_HDR,2.0CH,
z=14. 1080P_HDR,5.1CH,
z=15. 1080P_HDR,7.1CH
z=16. 4K30_HDR,2.0CH,
z=17. 4K30_HDR,5.1CH,
z=18. 4K30_HDR,7.1CH
z=19. 4K60(420)_HDR,2.0CH,
z=20. 4K60(420)_HDR,5.1CH,
z=21. 4K60(420)_HDR,7.1CH
z=22. 4K60(444)_HDR,2.0CH,
z=23. 4K60(444)_HDR,5.1CH,
z=24. 4K60(444)_HDR,7.1CH
z=25. 4K120(420)_HDR,2.0CH,
z=26. 4K120(420)_HDR,5.1CH,
z=27. 4K120(420)_HDR,7.1CH
z=28. 4K120(444)_HDR,2.0CH,
z=29. 4K120(444)_HDR,5.1CH,
z=30. 4K120(444)_HDR,7.1CH
z=31. FRL10G_8K_HDR,2.0CH,
z=32. FRL10G_8K_HDR,5.1CH,
z=33. FRL10G_8K_HDR,7.1CH
z=34. FRL12G_8K_HDR,2.0CH,
z=35. FRL12G_8K_HDR,5.1CH,
z=36. FRL12G_8K_HDR,7.1CH,
z=37. user1_EDID,
z=38. user2_EDID,
z=39, user3_EDID
s input 1
EDID 36!
input 1 EDID:
FRL12G_8K_
HDR,7.1CH
FRL12G_
8K_HDR,
7.1CH
