VCCX2 Controller Technical Guide
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
Missing EM1
Board
BI: 45 EM1 Expansion Board is
bad or missing.
Missing 12
Relay
Expansion
Board
BI: 46 The 12 Relay Expansion
Board is congured but not
detected.
On Board
Relay 1 Main
Fan
BI: 47 Current Status of Main Fan
Relay #1 on Main Board
On Board
Relay 2
BI: 48 Current Status of
Congurable Relay #2 on
Main Board
On Board
Relay 3
BI: 49 Current Status of
Congurable Relay #3 on
Main Board
On Board
Relay 4
BI: 50 Current Status of
Congurable Relay #4 on
Main Board
On Board
Relay 5
BI: 51 Current Status of
Congurable Relay #5 on
Main Board
On Board
Relay 6
BI: 52 Current Status of
Congurable Relay #6 on
Main Board
On Board
Relay 7
BI: 53 Current Status of
Congurable Relay #7 on
Main Board
On Board
Relay 8
BI: 54 Current Status of
Congurable Relay #8 on
Main Board
Expansion
Board EM1
Relay 1
BI: 55 Current Status of
Congurable Relay #1 on
EM1 Board
Expansion
Board EM1
Relay 2
BI: 56 Current Status of
Congurable Relay #2 on
EM1 Board
Expansion
Board EM1
Relay 3
BI: 57 Current Status of
Congurable Relay #3 on
EM1 Board
Expansion
Board EM1
Relay 4
BI: 58 Current Status of
Congurable Relay #4 on
EM1 Board
Expansion
Board EM1
Relay 5
BI: 59 Current Status of
Congurable Relay #5 on
EM1 Board
12 Relay
Expansion
Board Relay 1
BI: 60 Current Status of
Congurable Relay #1 on
12 Relay Board
12 Relay
Expansion
Board Relay 2
BI: 61 Current Status of
Congurable Relay #2 on
12 Relay Board
12 Relay
Expansion
Board Relay 3
BI: 62 Current Status of
Congurable Relay #3 on
12 Relay Board
12 Relay
Expansion
Board Relay 4
BI: 63 Current Status of
Congurable Relay #4 on
12 Relay Board
BACnet
®
Properties for the VCCX2 Controller
Parameter Object Description
Limits
12 Relay
Expansion
Board Relay 5
BI: 64 Current Status of
Congurable Relay #5 on
12 Relay Board
12 Relay
Expansion
Board Relay 6
BI: 65 Current Status of
Congurable Relay #6 on
12 Relay Board
12 Relay
Expansion
Board Relay 7
BI: 66 Current Status of
Congurable Relay #7 on
12 Relay Board
12 Relay
Expansion
Board Relay 8
BI: 67 Current Status of
Congurable Relay #8 on
12 Relay Board
12 Relay
Expansion
Board Relay 9
BI: 68 Current Status of
Congurable Relay #9 on
12 Relay Board
12 Relay
Expansion
Board Relay 10
BI: 69 Current Status of
Congurable Relay #10 on
12 Relay Board
12 Relay
Expansion
Board Relay 11
BI: 70 Current Status of
Congurable Relay #11 on
12 Relay Board
12 Relay
Expansion
Board Relay 12
BI: 71 Current Status of
Congurable Relay #12 on
12 Relay Board
Preheater
Enable Status
BI: 72 Status of Preheater
Enable Input
Preheater
Emergency
Shutdown
BI: 73 Status of Preheater
Emergency Shutdown Input
Preheater
Spare Binary
Input #3
BI: 74 Status of Preheater
Binary Input #3
MODGAS
Enable Status
BI: 75 Status of MODGAS
Controller
MHGR
Enable Status
BI: 76 Status of MHGRV
Controller
A1
Compressor
Enable
BI: 77 Current Status of Enable
Signal to Compressor A1
A2
Compressor
Enable
BI: 78 Current Status of Enable
Signal to Compressor A2
A1
Compressor
Alarms
BI: 79 Indicates an RSM alarm is
present on the A1 circuit.
A2
Compressor
Alarms
BI: 80 Indicates an RSM alarm is
present on the A2 circuit.
A1-2 Defrost
Switch
BI: 81 Outside Coil A1/A2 Temp
Switch for Defrost Mode
A1-2 Water
Proof of Flow
BI: 82 A1/A2 Water Proof of Flow
Switch
A1-4
Emergency
Shutdown
(RSMD)
BI: 83 Emergency Shutdown Input
on Module A
APPENDIX C
-
VCCX2 BACnet
®
VCCX2 BACnet
®
Parameters
