SPECIFICATIONS
1. Continuous 4W load 20Hz to 200Hz, < 0.05% THD, with input voltage at 13.8VDC.
2. Continuous 2W load 20Hz to 200Hz, < 0.1% THD, with input voltage at 13.8VDC.
Amplifier Section Orion 300D Orion 600D Orion 1200D Orion 2500D
Power Output 4W
(Watts)
1
175 x 1 250 x 1 425 x 1 1000 x 1
Power Output 2W
(Watts)
2
250 x 1 400 x 1 725 x 1 1700 x 1
Power Output 1W
(Watts)
300 x 1 600 x 1 1200 x 1 2500 x 1
Externally
Bridgeable
no yes yes no
Remote Gain
Function
yes yes yes yes
Distortion at Rated
Power
< 1.0% THD+N < 0.9% THD+N < 0.9% THD+N < 0.9% THD+N
Frequency
Response
20Hz to 200Hz
+0, -1dB
20Hz to 200Hz
+0, -1dB
20Hz to 200Hz
+0, -1dB
20Hz to 200Hz
+0, -1dB
Linear Bandwidth
10Hz to 500Hz
±3dB
10Hz to 500Hz
±3dB
10Hz to 500Hz
±3dB
10Hz to 500Hz
±3dB
Damping Factor > 50 > 50 > 50 > 50
Input Sensitivity 200mV to 5V rms 200mV to 5V rms 200mV to 5V rms 200mV to 5V rms
Input Impedance
40kW 40kW 40kW 40kW
Fuse Type (1) 30 Amp (1) 50 Amp MAXI (3) 40 Amp ATC None
Dimensions 13"x10.5"x2.3" 16.4"x10.5"x2.3" 18.7"x10.5"x2 27.2"x10.5"x2.3"
Weight 8 lbs. 13 lbs. 16 lbs. 24 lbs.
Crossover Section
Low Pass Crossover
Continuously
variable/
2
nd
Order/
4
th
Order
Continuously
variable/
2
nd
Order/
4
th
Order
Continuously
variable/
2
nd
Order/
4
th
Order
Continuously
variable/
2
nd
Order/
4
th
Order
Low Pass Frequency
Range
30Hz to 250Hz 30Hz to 250Hz 30Hz to 250Hz 30Hz to 250Hz
High Pass Filter
Continuously
variable/
2
nd
Order/
4
th
Order
Continuously
variable/
2
nd
Order/
4
th
Order
Continuously
variable/
2
nd
Order/
4
th
Order
Continuously
variable/
2
nd
Order/
4
th
Order
High Pass
Frequency
20Hz to 150Hz 10Hz to 150Hz 10Hz to 150Hz 10Hz to 150Hz
INTELLI Q 0–10dB boost 0–10dB boost 0–10dB boost 0–10dB boost
