BRIDGED MODE
CO600.4/CO1000.4
BRIDGED
REM GND
+12V
POWER INPUT
CH1 CH2
CH3 CH4
FUSES
SPEAKER OUTPUT
MONO SPEAKER
4~8Ohm
MONO SPEAKER
4~8Ohm
CO1500.4/CO2000.4
BRIDGED
REM GND
+12V
POWER INPUT
CH1 CH2
CH3 CH4
FUSES
SPEAKER OUTPUT
MONO SPEAKER
4~8Ohm
MONO SPEAKER
4~8Ohm
CO1500.5 / CO2700.5
MONO SPEAKER
4~8Ohm
MONO SPEAKER
4~8Ohm
BRIDGED MODE
CO600.2
SPEAKER OUTPUT
REM
+12V
GND
POWER INPUT
LEFT RIGHT
BRIDGED
FUSES
25A X 2
MONO SPEAKER
4~8Ohm
SPEAKER OUTPUT
REM
+12V
GND
POWER INPUT
FUSE
LEFT RIGHT
BRIDGED
25A
MONO SPEAKER
4~8Ohm
CO300.2
