15
SPEAKERS CONNECTIONS SPEAKERS CONNECTIONS
16
CB2500.1D
POWER INPUT
SPEAKER OUTPUT
+12V
REM GND
FUSES
30A X 4
MIN 1
+ +
MONO SPEAKER
1~4Ohm
CB3500.1D
POWER INPUT
SPEAKER OUTPUT
+12V
REM GND
FUSES
40A X 5
MIN 1
+ +
MONO SPEAKER
1~4Ohm
CB1500.1D2
POWER INPU T
SPEAKER OUTPUT
FUSES
+12V
REM GND
MIN 2
40A X 3
+ +
MONO SPEAKER
2~4Ohm
CB5000.1D
REM
POWER INPUT
SPEAKER OUTPUT
+12V
GND
+ +
MONO SPEAKER
2~4Ohm
CB5000.1D:250A
