13 14
SPEAKERS CONNECTIONS SPEAKERS CONNECTIONS
CB2700.5
SPEAKER OUTPUT
CH5
BRIDGED
CH3 CH4
CH1 CH2
SPEAKER OUTPUT
MIN 1
REM
POWER INPUT
GND
+12V
CB2700.5:150A
CB1000.1D
+ +
MONO SPEAKER
1~4Ohm
POWER INPUT
SPEAKER OUTPUT
+12V
REM GND
MIN 1
FUSES
40A X 2
CB1500.1D
POWER INPUT
SPEAKER OUTPUT
FUSES
+12V
REM GND
MIN 1
40A X 3
+ +
MONO SPEAKER
1~4Ohm
CB1500.5
CB1500.5:100A
CB1000.1M2
+ +
MONO SPEAKER
2~4Ohm
FUSES
POWER INPUT
SPEAKER OUTPUT
REM+12V
GND
MIN 2
30A X 3
