Orion Machine Manual
Revision 3.0 Flex Stretchwrapper
15 February 2016 System Operation
Page 3-41
The Outputs Screens
This is the Outputs screen. This screen shows the status of the machine outputs. There is
another screen similar to this for displaying input status.
Figure 3 - 29
The Outputs Screen
Table 3-28. The Output Screen Button Descriptions
STATE 1 DESCRIPTION
Grey represents an inactive output. Green represents an active output.
