System Description
Machine Specifications
Utilities
• 115 / 1ph / 60hz 20 Amp Service
Standard Speed
• 16 Rpm Variable Tower Speed Vfd Controlled Motor**
Drive
• Heavy Duty Chain Drive
• Electronically Adjustable Acceleration/deceleration And Running Speeds (At Vfd)
• Positive Alignment Feature (True Home Position)
Control Features
• Nema 12 Control Panel
• User Friendly Interface with Graphical Maintenance Reminders
• IP Address is Modifiable for Networking
• Easy to Use Icon Based Interface
• Web-based Production Data Dashboard
• Optional Wireless Connection to the PLC/ HMI
• Downloadable VFD Parameters
• Variable Speed Film Carriage Up/ Down Control
• Film Carriage Manual Jog Functionality
• Photocell For Automatic Load Height Detection
• Main Drive Jogging
• Variable Speed Main Drive
• Semi-automatic Reinforce Wrap Feature
• On-Screen Interactive Troubleshooting Guide
Film Delivery
• Instathread Full Corner Compensating Powered Film Drive.
• 260 % Stretch From The Factory. 20" Film Tension Delivery System. **optional 30"
• Full Authority, Corner Compensating, Vfd Powered Prestretch
• Electronic Film Tension Control Adjustment On The Panel < Or = 90 Ga Film Capac-
ity. Higher Gauge Film Requires A Heavy Film Upgrade.
• Film Carriage Elevator Drive
• High Strength Belt Lift Optional Chain Lift
