Orion LCD Monitor User Manual

C. PIP
Option Function Value
PIP Activates the PIP feature. Off or On
Input Source Selects the input source for the PIP area. See table below
PIP Mode
Enables 3 screen size.4:3 side by corner, 4:3 side by 4: 3,
and full screen side by side.
PIP, PBP1 or PBP2
PIP Size Selects the size of PIP screen. Size1, Size2 or Size3
Position
Selects the position of PIP screen. Right of Bottom, Left of
Bottom, Left of Top and Right of Top.
RB, LB, LT or RT
Swap Alternates between the main and sub picture
Sound Select Selects the sound source from either the Main or PIP Main or Sub
Input Source
Main Sub
Available
combination
AV1 or AV2 AV1 or AV2
AV1 or AV2 RGB-PC, DVI or HDMI
RGB-PC, DVI or HDMI AV1 or AV2
Unavailable
combination
RGB-PC, DVI or HDMI RGB-PC, DVI or HDMI
- 13 -
