Orion OLM-5510 User Manual

- 70 - - 71 -
ORION
Innitely Expandable
- Receive from MLCD
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
3.11. FAN Mode
- Command for FAN control
- It is available only on Power On (Operative) status.
- CMD: 0xD8
- Send to MLCD
A. NormalCommand
STX CMD Length
Data
ETX
ID Master Control
Value 0x02 0xD8 0x02 Variable 0x01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*Control:Auto(0x00),Full(0x01)
B. BroadcastCommand
STX CMD Length
Data
ETX
ID Control
Value 0x02 0xD8 0x02 0x00 Variable 0x03
*But,therewillbenoreturncommunication.(Onewaycommand)
- Receive from MLCD
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 0xD8 0x02 Variable 0x01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
3.12. Elapsed Time
- Command for informing the elapsed time of each LCD set. (Basic unit: hour)
- It is available only on Power On (Operative) status.
- CMD : 0x77 (Get), 0x7B (Initial)
- Send to MLCD
STX CMD Length
Data
ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 0x03
*IDrange(Program):0x01(1)~0xFF(255) 
*Itisnotapplicableas"Broad-cast"command
- Receive from MLCD
STX CMD Length
Data
Check
Sum
ETX
ID Master Elapsed Time
Value 0x02 Variable 0x08 Variable 0X01 … Variable 0x03
Hundred
thousands
ten thou-
sands
thousands hundreds ten one
Variable Variable Variable Variable Variable Variable
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:Execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
*ElapsedTime
-Hundredthousands,tenthousands,thousands,hundreds,tens,ones:0(0x00)~9(0x09)rangevalue.
3.13. IP Serial Number
- Command for assigning and identifying the serial numbers of each IP board. (8 digit)
- CMD: 0x75 (Get S/N), 0x76 (Set S/N)
- Send to MLCD
STX CMD Length
Data
ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*"Get/SetIPSerialNumber"(0x75/0x76)commandisnotapplicableas"Broad-cast"command,becauseeachLCDshouldhavean
uniqueserialnumber.
- Receive from MLCD
STX CMD Length
Data
Check
Sum
ETX
ID Master SN
Value 0x02 Variable 0x0A Variable 0x01 … Variable 0x03
0 1st 2nd 3rd 4th 5th 6th 7th
Variable Variable Variable Variable Variable Variable Variable Variable
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:Execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
*ElapsedTime
-0,1st,2nd,3rd,4th,5th,6th,7th:0(0x00)~9(0x09)rangevalue
3.14. Get Current Status
- Command for obtain the current LCD (IP) information
- It is available only on Power On (Operative) status.
- CMD: 0x87
- Send to MLCD
STX CMD Length
Data
ETX
ID Master
Value 0x02 0x87 0x02 Variable 0X01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*Itcannotbeusedas"Broad-cast"command.
