Orion OLM-5510 User Manual

- 68 - - 69 -
ORION
Innitely Expandable
3.7. Auto-Power Mode
- Configuration for automatic power on by AC power connection.
- It is available only on Power On (Operative) status.
- CMD: 0x62(On), 0x63(Off)
- Send to MLCD
A. NormalCommand
STX CMD Length
Data
ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
B. BroadcastCommand
STX CMD Length Data: ID ETX
Value 0x02 Variable 0x01 0x00 0x03
*AllLCDwilldothesameoperationsimultaneously.But,therewillbenoreturncommunication.(Onewaycommand)
- Receive from MLCD
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:execute"Not"operationafteraddingallthevaluesin"STX~Data"area..
3.8. DTV Over-Scan On/Off
- Users can select Over-scan when input is DTV resolution from DVI. It is only available with DVI mode.
- It is usable only at Power on status.
- CMD: 0xE4(On), 0xE5(Off)
- Send to MLCD
A. NormalCommand
STX CMD Length
Data
ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
B. BroadcastCommand
STX CMD Length Data: ID ETX
Value 0x02 Variable 0x01 0x00 0x03
*MakeallLCDdothesameoperation.But,therewillbenoreturncommunication.(Onewaycommand)
- Receive from MLCD
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*CheckSum:Execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
3.9. Over-Temperature Shut-down Control
- Commands for automatic power off making MLCD set stand-by and OSD warning method, if IP board
temperature is 95℃ or higher.
- It is available only on Power On (Operative) status.
- The initial configuration is "Over Temperature Shut-down Enable."
- CMD
*0x64(OverTemperatureShut-downEnable)
:IncaseIPboardtemperatureis95℃orhigher,displaywarningsignal"HighTemperature"inredfor1minuteatthelowerleft
cornerofMLCDandpoweroffautomatically(Stand-bymode.)
*0x65(OverTemperatureShut-downDisable)
:IncaseIPboardtemperatureis95℃orhigher,displaywarningsignal"HighTemperature"inredfor3secondsatthelowerleft
cornerofMLCDandrepeatthewarningevery60seconds.(Noautomaticpoweroff)
- Send to MLCD
A. NormalCommand
STX CMD
Length
Data
ETX
ID Master
Value 0x02 Variable 0x02 Variable 0x01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
B. BroadcastCommand
STX CMD Length Data: ID ETX
Value 0x02 Variable 0x01 0x00 0x03
*MakeallLCDdothesameoperation.But,therewillbenoreturncommunication.(Onewaycommand)
- Receive from MLCD
STX CMD
Length
Data
Check Sum ETX
ID Master
Value 0x02 Variable 0x02 Variable 0x01 Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255) 
*CheckSum:AddthesumfromSTXtoDataandexecute"Not"operation.
3.10. Test Pattern
- Command for checking the operating status with internal patterns
- It is available only on Power On (Operative) status.
- CMD: 0x57 (Red), 0x58 (Green), 0x59 (Blue), 0x5A (White), 0x5B (Screen)
- Send to MLCD
A. NormalCommand
STX CMD Length
Data
ETX
ID Master
Value 0x02 Variable 0x02 Variable 0X01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
B. BroadcastCommand
STX CMD Length Data: ID ETX
Value 0x02 Variable 0x01 0x00 0x03
*MakeallLCDdothesameoperation.But,therewillbenoreturncommunication.(Onewaycommand)
MLCD
