Specifications
■RKS500F
Model RKS500F
Cooling capacity kW * 1.3
／
1.4
External finish Munsell No
．
7.5
Ｙ
7.5
／
0.5
External dimensions (H×D×W) mm 333×375×484
Mass(Tank dryness) kg Approx. 35
Ambient temperature range
℃
5 to 40
Cold
water
Service water temperature range
℃
5 to 25
The amount of the use minimum
circulation
L/min 15 or more
Water in and outlet connection dia.
Rp3/4
Electrical
ratings
Power source V
･
Hz 3 phase. 200 +/-10%(50
／
60)
Power consumption W * 715
／
850
Current A * 3.0
／
2.8
Power supply capacity kVA 1.3
Equipment specifications
Compressor W Fully hermetic, rotary type 600
Condenser Fin and tube type, forced air cooling
Chiller
Structure Shell and coil type
Material Shell: ABS resin Coil: SUS304
Circulation pump
for chiller
Structure Magnet drive type
Output W 20
Circulation
flow ran
g
e
L/min
15 to 24
／
15 to 27
Refrigerant control mechanism Capillary tube
Fan motor output W
･
mm 10
・
φ250
Refrigerant R-407C
Thermostat Electric type
（
with alarm monitor
）
Protective
devices
Refrigerant compressor
Motor protector
Refrigerant cycle
High-pressure switch
Temperature switch
Remarks
* Cold water temperature 20
℃
, Room temperature 32
℃
.
・
Cooling capacity is at least 95% of listed figures.
・
Accessories:
(1)Filter for condenser
(2)Strainer assembly (Foot valve, Wire mesh, Hose band φ60) : 1 set
(3)Rubber joints (φ25×φ31): 1 set
(4)Hose band(φ32 wire type) : 2 pieces
(5)A wire for remote terminals connection : 1 piece
・
Optional: Air direction plate assembly.
・
Water tank capacity 25L or more.
