Machine Layout
External Appearance
External Appearance
■External View
(Front)
Pump priming port
(Priming port cap)
Control Plate
Power cord access hole
φ
30
(incl. grommet)
Water inlet Rp3/4
Drain M10
(Drain plug)
Water outlet Rp3/4
Specification plate
(Rear)
Condenser filter and Condenser
