63
REV. 00 - Cod.: 1500154
Operation and maintenance manual / Ed. 10 - 2005
VACUUM CHAMBER
PACKAGING MACHINES
GB
GB
GB
7.3.1 CLEANING THE PLEXIGLAS COVER
• Wipe using a cloth soaked in potable water or a detergent specially meant for Plexiglas (maximum temperature 40°C).
• Do not use other types of detergents.
• Dry the cover thoroughly.
7.3.2 CLEANING THE SEALING BARS
ATTENTION!
Do not start cleaning operations with the sealing bars hot, as there is danger of burns.
• Clean the upper part of the sealing bar using a clean cloth soaked in potable water.
7.3.3 CLEANING THE VACUUM CHAMBER
1) Switch the machine off by means of the ON/OFF main switch and disconnect the plug from
the mains socket.
2) Disconnect the two sealing bar connection wires (A - Fig. 1).
3) Remove the sealing bar together with the connection wires (Fig. 2).
4) Hold the sealbag and pull it upwards (B - Fig. 3).
5) Insert the safety cap (C) in the central opening as shown in (Fig. 4).
6) Using a cloth soaked in a detergent and/or disinfectant solution, clean the
bottom and sides of the vacuum chamber (Fig. 5); after cleaning, refit the parts by repeating
the above operations in reverse order.
7.3.4 DISINFECTING THE MACHINE
• Switch the machine off by means of the ON/OFF main switch and disconnect the plug from the mains socket.
• Spray the machine’s stainless steel surface with an alcohol-based disinfectant. Do not spray on the electrical parts or in the machine’s air vents.
• Leave the disinfectant to act for a few minutes.
• Wipe with a cloth soaked in potable water, then dry thoroughly with a clean cloth.
Fig. 1
MAINTENANCE
Fig. 2
Fig. 4
Fig. 3
Fig. 5
•
A
•
A
•
B
•
C
