Page 10 Operation Manual - 2500
ENGLISH
STOVE CONTROLS
The stove, the pellet feeding system and the blowers are controlled by a control panel on the right-
hand side of the stove. The control panel buttons and display areas are as follows:
3
1
5
2
4
6
A
C
B
Stove controls
No Description
A
Control panel display area.
B
Stove state display area.
C
Stove heating intensity display area, level 1 to 6.
1
MODE: the «MODE» button is used to either turn off the appliance (OFF), turn it on in manual
operation (MANUAL) or in thermostatic operation (THERMOSTAT).
2
RESET: The «RESET» button is used to reset the stove after the appearance of most of the
warning codes.
3
AUX: The «AUX» button is used to adjust the convection air speed.
4
AUGER: The «Auger» button is used to fill the auger with pellets.
5
MINUS: The « - » button is used to reduce the pellet feeding rate thus reducing the heat
output of the stove.
6
PLUS: The « + » button is used to increase the pellet feeding rate thus increasing the heat
output of the stove.
