Page 7Operation Manual - 2500
ENGLISH
SPECIFICATIONS
Model 2500 (OP00025)
Fuel Type
1
Wood pellets (Premium grade or better)
Recommended heating area (sq. ft
.
)
2
500 - 2,000 pi
2
(46 - 186 m
2
)
Hopper capacity 60 lb (27,3 kg)
Maximum burn time
2
51 hours
Recommended chimney diameter 3 in. or 4 in (see installation manual).
Flue outlet diameter 3 po. (76 mm)
Type of chimney
ULC/ORD-C441, CAN/ULC S609
UL 641 (TYPE L)
Approved for alcove installation Yes
Approved for mobile home installation
3
Yes
Shipping weight (without option) 286 lb (130 kg)
Appliance weight (without option) 253 lb (115 kg)
Baffle material Stainless Steel
Type of door Simple, glass with cast iron frame
Type of glass Ceramic glass
Blower Included (176 CFM)
Noise level at 6 feet
Min. 47 dBa (+/- 3 dBa)
Max. 60 dBa (+/- 3 dBa)
1
Grades of pellet fuel are determined by organizations such as Pellet Fuels Institute (PFI), ENplus and CANplus.
2
Recommended heating area and maximum burn time may vary subject to location in home, chimney draft, heat loss factors, climate, fuel type, feed
rate, fuel level, and other variables. The recommended heated area for a given appliance is dened by the manufacturer as its capacity to maintain a
minimum acceptable temperature considering that the space conguration and the presence of heat distribution systems have a signicant impact
in making heat circulation optimum.
3
Mobile home (Canada) or manufactured home (USA): The US department of Housing and Urban Development describes “manufactured homes”
better known as “mobile homes” as followed; buildings built on xed wheels and those transported on temporary wheels/axles and set on a
permanent foundation. In Canada, a mobile home is a dwelling for which the manufacture and assembly of each component is completed or
substantially completed prior to being moved to a site for installation on a foundation and connection to service facilities and which conforms to the
CAN/CSA-Z240 MH standard.
