Page 22 Operation Manual - 2500
ENGLISH
Heat Exchangers and Exhaust Channels
Activate the cleaning rod a couple of times
Brush and vaccum inside the heat exchanger channel, when necessary.
2x
7/16''
Remove screws (2x) Pull on left side panel
2x
Then, pull Remove wing nuts (2x)
1
2
Brush and vacuum Replace gasket, if necessary
To Next Page
