WARNING!
There are no user serviceable elements incorporated into the motor, motor
controller, batteries, battery charger, throttle, or wiring harness of your OSET
electric bike. DO NOT ATTEMPT TO DISASSEMBLE OR ADJUST ANY OF
THESE COMPONENTS. Doing so may cause extensive damage to these
components, will void your warranty, and may cause a hazardous condition. If
you cannot resolve a problem using this owners manual, contact your OSET
authorized dealer, or call the OSET Customer Service Department for
assistance.
WIRING DIAGRAM:
