EN | Installation
13
5.2 Installation
Remove the lid of the fan.
5 Losen the screws.
6 Lift off the lid.
Placement.
7 The wall fan is mounted to duct,
such as spiro.
8 Make the lead-through sealing accurately
to avoid moisture damage on the building.
9 Apply sealant between the top of the fan
and the wall.
10 Insulate the outside of the duct to avoid
condensation and downdraughts.
Mounting.
11 Secure the fan with screws that is suitable
for the construction and condition of the wall.
There are screw holes in all four corners.
6
5
7
8
9
10
11
5
