OTC 5019A - Maintenance and Optional Equipment

1. Positionthejackunderthetransmission.
2. Closethecontrolvalve.Operatethepumphandletoraisetheboomandalignthemountingplatewiththetransmission.
SeeFigure2.
3. Removethetransmissionaccordingtotheinstructionsinthevehicleservicemanual.
4. Positionthetransmissiononthemountingplate,restingagainsttheangleplatesasshowninFigure2.
• Thetransmissionmountingplatemaybetiltedforwardandbackwardbyadjustingthelinkagearm(No.538311).
• Thetransmissionmountingplatemaybetiltedside-to-sidebyadjustingthehexhd.capscrews.
5. Securethetransmissiontothemountingplate.
6. Lowertheloadbyslowlyopeningthecontrolvalve.Usethecontrolvalvetoregulatehowfasttheboomislowered.
Optional Equipment - OTC AdjustaGrip
®
Universal Mounting Arm (No. 538578)
Parts List & Operating Instructions Form No. 540403
Operating Instructions
Figure 2
Thetransmissionmustrest
againsttheangleplatesasshown.
Right Angle
Mounting Ear
Figure 3
Angle Plates
Angle Plate
Maintenance
1. Completelylowerthejackanytimeitisnotbeingused.
2. Thehydraulicpumpandramassemblyshouldbedrained,ushed,andrelledwithoilatleastonceeachyear.Use
ahighgradehydraulicoilsuchasOTCNo.9636oranequivalent(215SUSviscosityratingat100°F).
3. Lubricatecasterswivelplatesandwheelseverysixmonthsusingpressuregungrease.
4. LubricateliftarmpivotpointsasneededwithSAE30motoroil.
Mounting
Plate
No. 538320
OTC'suniversalmountingarmsmaybeusedtomountotherlargetransmissions
tothelowlifttransmissionjack.(OrderNo.305811foroneuniversalmountingarm;
ordereacharmseparately.)
1. Removethetransmissionmountingplate(No.538316),bolts,washers,andhex
nuts.
2. Fastentheuniversalmountingarmstothetopofthemountingplate(No.538320)
usingthewashersandnutsprovided.SeeFigure3.
a. Loosenallthejointsintheadjust-a-griparms.
b. Locatetherightanglemountingearofeacharmoveraslotinthemounting
plate,andinstallawasherandnut.
c. Usecapscrewstoattachatleasttwoofthearmstothetransmission.
