OTC 5019A - Light-Duty Transmission Adapters

Form No. 561957
Parts List &
Operating Instructions
for: 561949
Light-Duty Transmission Adapters
Maximum Capacity: 454 kg (1000 lbs.)
Description:
Four universal mounting adapters
designed to be used on a transmission
jack mounting plate for the purpose
of transporting and repairing vehicle
transmissions.
Use with:
•
OTC No. 5019A, 5078, or 1522A
Transmission Jack for removal and
installation of differential assemblies.
•
OTC No. 5130 DriveMaster™
Driveline Lift for removal and
installation of driveline components.
Item Part No.
No. No. Req'd Description
1 561947 1 Transmission Adapter Assembly (consists
ofadapter,atwasher,hexnut)
Parts List
Item
No. Qty. Description
2 4 Carriage Bolt — 1/2-13 x 30.48 mm (1.25 in.)
3 4 FlangeNut—1/2-13thread
4 4 Washer—plain,type“A”
5 1 RatchetStrap—4ft.(122cm)
Repair Kit No. 569966
1
5
2
3
4
Mounting plate for
No. 5130 shown
(not included).
