1.3 EXAMPLE CONNECTIONS
03
1.2 REAR PANEL
1 IN L/MONO : Left or Mono input. Unbalanced 1/4” jack
2 IN R : Right input. Unbalanced 1/4” jack
3 OUT L : Left output. Unbalanced 1/4” jack
4 OUT R : Right output. Unbalanced 1/4” jack
5 MIDI IN : MIDI input
6 MIDI OUT : MIDI output
7 AC ADAPTOR INPUT : Only use a 9 volts AC adaptor, 500 mA minimum with a 2.1mm plug
8 POWER SWITCH
