OTT netDL 500 - Page 11

11
Serial interface
(RS-232/COM 2)
for extended communication
Plug-in screw terminal strip
for voltage supply
and switching contacts
Jog shuttle
Serial interface
(RS-232/COM 1)
Serial interface
(RS-232/COM 1)
Plug-in screw terminal strip
for voltage supply
and switching contacts
Fig. 4: Datalogger rear panels
including the screw terminal strips
for power supply and switching contacts.
