3) Screw in the set screws.
4) Use the torque wrench to tighten the set screws (10Nm).
5) Replace any set screws that are protruding or recessed too much with suitable ones (see
selection table).
6)
For final assembly:
Use the torque wrench to retighten the set screws (15Nm).
Selection table for set screws
Reference number Length (mm)
506G3=M8X12-V 12
506G3=M8X14 14
506G3=M8X16 16
5.3.4 Determining Socket Flexion
>
Required measuring equipment and materials:
662M4 Goniometer, Pin
1) On the lateral side of the residual limb, mark the course of the thigh bone.
2) With the patient lying down, instruct the patient to fully bend the contralateral leg and hold it
with the hands.
3) Slide the flat hand under the patient's back (see fig.3).
4) Bring the residual limb to full flexion.
5) Slowly move the residual limb in the extension direction until pressure on the hand is reduced.
6) Slowly move the residual limb back in the flexion direction until the pressure reduction stops.
7) In this residual limb position, measure the angle α (hip flexion contracture) with the goniomet
er.
8)
INFORMATION: Correct socket flexion (β) during bench alignment is crucial for optim
um walking. Take the individual situation of the patient into account for the tolerance.
If the angle α=0°, the optimum value of the angle β = 3to 5° to the alignment reference line.
If the angle α>0°, the optimum value of the angle β = α+5to 10°.
5.3.5 Determining the Socket Reference Point
>
Required measuring equipment and materials:
743A80 50:50 Gauge, Pin
1) Position the 50:50 gauge on the lateral side of the prosthetic socket in the distal area and
mark a centre point (see fig.5).
2) Position the 50:50 gauge in the proximal area and mark a centre point .
3) Using these points, mark the centre line of the prosthetic socket.
4) Clearly mark the tuberosity height as the tuberosity reference point on the centre line.
5) Clearly mark the socket reference point 30mm proximal to the tuberosity reference point.
5.4 Static Alignment
Static Alignment Process
+ = anterior placement / – = posterior placement (in relation to the load line)
No. see fig.6
Required equipment:
743L100 L.A.S.A.R. Posture, 3D L.A.S.A.R. Posture 743L500
 
To determine the load line , position the patient on the L.A.S.A.R. Posture as follows:
• Prosthetic foot (with shoe) on force measurement plate (sufficient load: >35% body weight)
• Other foot (with shoe) on height compensation plate
• The tips of the shoes are in one line
