10
Leak Test Diagram
ASSEMBLY IS NOW COMPLETE.
PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON
OPERATION AND MAINTENANCE.
11a. Connect the gas hose (B2) to the barbecue (Before the Leak Test). Ensure the mating
faces of the connection are clean and not damaged. Do not use any sealing tape, paste, or
liquid on the joint. The nut must be tightened with the use of a spanner. Do not use force which
may damage the assembly.
11b. All joints and connections must now be leak tested before using the barbecue. For details
of leak testing, please refer to instructions on Page 12. Number of valves to be leak tested will
vary with model of barbecue.
11
