2
CODE PART QTY
Outback®
2 Burner
Outback®
3 Burner
Outback®
4 Burner
LID
A1 Lid Handle 1
A2 Flat Lid (Pre-Assembled to Body) 1
BODY
B1 Burner
2 3 4
B2 Hose and Hose Clip 1
B3 Body (see Part A2: Flat Lid) 1
B4 Control Panel 1
B5 Drip Tray 1
B6 Drip Tray Handle 1
B7 Cooking Grill
1 2 1
B8 Reversible Cooking Griddle 1
B9 Lava Rock Basket
1 2 1
B10 Lava Rock (Packed in Basket)
1 2 1
B11 Knob
2 3 4
TROLLEY
C1 Side Shelf 2
C2 Short Leg Front 1
C4 Long Leg Front 1
C6 Screen 1
C7 Leg Endcap 2
C8 Wheel 2
C9 Hubcap 2
C10 Axle 1
C11 Trolley Base 1
HARDWARE
D1 Handle Bolt 2
D2 Trolley Bolt 24
D3 Body Support Bolt 8
D4 Spacer 8
D5 Wing Nut 8
D6 Locknut 2
D7 Washer 2
C3 Short Leg Rear 1
C5 Long Leg Rear 1
A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice.
For more details on hardware, please see ‘Hardware Reference Diagram’.
Pre-Assembled Component
Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
To Next Page
