10
Attach the Bottom Shelf (C22) to the Gas Bottle
Holder (C17) using ST4.8x15 Screws (D6).
Take care not to over tighten these screws
which will damage the plastic gas bottle holder.
Attach the leg assembly to the bottom
shelf assembly using M6x15 Bolts (D1).
4
3
Excel 100T Excel 200T Excel 300T
Excel 100T Excel 200T Excel 300T
C22
C17
D6
D1
