CODE PART QTY
Outback® Meteor 4 Burner
Gas BBQ
HOOD
A1 Hood (Pre-Assembled to Body) 1
A2 Hood Handle 1
A3 Warming Rack 1
BODY
B1 Barbecue Body 1
B2 Burner 4
B3 Control Panel 1
B4 Knob 4
B5 Hose and Regulator Assembly 1
B6 Flame Tamer 4
B7 Cooking Grill 2
B8 Drip Tray Left Bracket 1
B9 Drip Tray Right Bracket 1
B11 Charcoal Basket 1
TROLLEY
C1 Side Burner Shelf 1
C2 Side Burner Shelf Panel 1
C3 Side Burner Grid 1
C4 Knob Bezel 1
C5 Side Burner Knob 1
C6 Ignition Button 1
C7 Side Burner 1
C8 Side Shelf 1
C9 Side Shelf Panel 1
C10 Left Front Leg 1
C11 Left Rear Leg 1
C12 Right Front Leg 1
C13 Right Rear Leg 1
C14 Upper Support 1
C15 Storage Box Handle 1
C16 Storage Box 1
C17 Front Panel 1
C18 Side Panel 4
C19 Bottom Panel 1
C20 Wheel 2
C21 Wheel Hubcap 2
C22 Axle 1
C23 Body Support A 2
C24 Body Support B 2
HARDWARE
D1 ST4.0x10 Screw 28
D2 M4x10 Bolt 3
D3 M4x10 Step Bolt 4
D4 M6x15 Bolt 16
D5 M6x40 Bolt 16
D6 M6 Nut 12
D7 Locknut 2
B10 Drip Tray 1
Pre-Assembled Component
Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
