Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue
model.
Pre-Assembled Component H Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
Body
Assembly
CODE PART QTY OMEGA 200 OMEGA 250
A1 Flame Tamer 1
3 3
A2 Burner 1
3 3
A3 Hood Handle 1
3 3
A4 Hood 1
3 3
A5 Body 1
3 3
A6 Grease Cup Holder 1
3 3
A7 Grease Cup 1
3 3
A8 Cooking Grill 1
3 3
A9 Upper Hinge Bracket 2
3 3
A10 Lower Hinge Bracket 2
3 3
A11 Main Electrode (with Gas Collector Box) 1
3 3
A12 Warming Rack 1
3 3
A13 Outback® Logo Badge 1
3 3
A14 Hood Handle Heat Shield 1
3 3
A15 Heat Indicator 1
3 3
Upper
Trolley
B1 Control Panel 1
3 3
B2 Ignition Button 1
3 3
B3 Knob 2
3 3
B4 Arch Support 2
3 3
B5 Hose/Regulator Assembly 1
3 3
B6 Plastic Side Shelf
H
2 1
B7 Side Burner Knob 1
3
B8 Side Burner Grid 1
3
B9 Side Burner Electrode 1
3
B10 Side Burner 1
3
B11 Side Burner Shelf 1
3
B12 Side Burner Valve/Hose Assembly 1
3
B13 Hinge Spindle 2
3 3
B14 R Clip 2
3 3
B15 Body Spacer 4
3 3
B16 Control Panel Heat Shield 1
3 3
B17 Valve Assembly 1
3 3
B18 Rear Support 1
3 3
B19 Side Shelf Bracket A
H
2 1
B20 Side Shelf Bracket B
H
2 1
Lower
Trolley
C1 Left Front Leg 1
3 3
C2 Left Rear Leg 1
3 3
C3 Short Axle 2
3 3
C4 Wheel 2
3 3
C5 Hubcap 2
3 3
C6 Screen 1
3 3
C7 Leg Endcap 2
3 3
C8 Right Front Leg 1
3 3
C9 Right Rear Leg 1
3 3
C10 Bottom Shelf 1
3 3
C11 Leg Support 2
3 3
Hardware
D1 M5x10 Bolt 2
3 3
D2 M6x30 Bolt 4
3 3
D3 M6x30 Bolt 4
3 3
D4 M6x40 Bolt 8
3 3
D5 M6x50 Bolt 4
3 3
D6 Axle Clip 2
3 3
D7 M6 Nut 16
3 3
D8 Shelf Spacer 8
3 3
D9 Shelf Washer 8
3 3
